Specifications
|
||
|---|---|---|
| Model | UISP-FIBER-XGS | |
| Description | Optical network unit (ONU) for XGS-PON, delivering 10 Gbps symmetrical uplink/downlink speeds over distances up to 20 km; compatible only with UISP Fiber XGS OLT | |
| Networking Interfaces | (1) SC/APC ITU-G.9807 XGS-PON WAN port (1) 1/2.5/5/10 GbE RJ45 LAN port | |
| Management Interface | Ethernet in-band PON | |
| Supported Data Rates | Downstream: 9.95 Gbps Upstream: 9.95 Gbps LAN: 1 / 2.5 / 5 / 10 Gbps | |
| Max Distance | 20 km over single-mode fiber | |
| Optical Wavelength | TX: 1270 nm, RX: 1577 nm | |
| Line Code | Scrambled NRZ | |
| TX Power Range | 4 to 9 dBm | |
| RX Sensitivity Range | -9 to -28 dBm | |
| Power Method | USB-C 5V DC, 3A 24V Passive PoE (10-30V DC) | |
| Max Power Consumption | 8 W | |
| Dimensions | 100 x 100 x 27 mm (3.9 x 3.9 x 1.1″) | |
| Weight | 220 g (0.49 lb) | |
| Enclosure Material | UV-stabilized polycarbonate | |
| Operating Temperature | -15 to 45°C (5 to 113°F) | |
| Operating Humidity | 10 to 95% non-condensing | |
| Memory | 256 MB DDR | |
| Storage | 32 MB NOR flash | |
| Certifications | CE, FCC, IC | |
| NDAA Compliant | Yes | |
Ubiquiti UniFi UISP-FIBER-XGS 10G XGS-PON ONU with 10 GbE LAN Price in Dubai UAE
