Specifications
|
||
|---|---|---|
| Model | SFP-25G-SR-B6-ISP (Bundle of 6x SFP-25G-SR modules) | |
| Product Type | Optical Transceiver Bundle | |
| Form Factor | SFP28 (Small Form-factor Pluggable 28) | |
| Data Rate | 25 Gbps | |
| Transmission Distance | Up to 100 meters (OM4) / 70 meters (OM3) | |
| Wavelength | 850 nm (Short Range) | |
| Fiber Type | Multi-mode Fiber (OM3/OM4) | |
| Connector Type | LC Duplex | |
| Interface Standard | 25GBASE-SR (IEEE 802.3by compliant) | |
| Transmitter Type | VCSEL (Vertical Cavity Surface Emitting Laser) | |
| Receiver Type | PIN Photodiode | |
| Digital Diagnostic Monitoring (DDM) | Supported (real-time monitoring of optical parameters) | |
| Power Consumption | < 1W (typical) | |
| Hot Swappable | Yes | |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) | |
| Compliance | RoHS Compliant, MSA Compliant, IEEE Standard Compatible | |
| Use Case | Short-distance 25G Ethernet over multi-mode fiber | |
Huawei SFP-25G-SR-B6-ISP DCN Bundle (6* SFP-25G-SR),25GBase-SR Optical Transceiver,SFP28,25G,Multi-mode Module Price in Dubai UAE
Enquire on Whatsapp
Description
