Specifications
|
||
|---|---|---|
| Brand | DME PROLINK | |
| Model Number | D1619‑LCA77A21 | |
| Product Name | LC/APC Single‑Mode G.657A2 Fiber Optic Pigtail | |
| Connector Type | LC/APC (Angled Physical Contact) | |
| Polish Type | APC | |
| Fiber Type | Single‑mode, G.657A2 bend‑insensitive fiber | |
| Cable Type | Pigtail (single‑ended fiber with pre‑terminated connector) | |
| Cable Diameter | ~2.0 mm outer diameter | |
| Cable Length | 1 m (as indicated by part code “77A21”) | |
| Jacket Material | LSZH (Low Smoke Zero Halogen) | |
| Jacket Colour | Yellow (standard for single‑mode) | |
| Insertion Loss | ≤ 0.30 dB | |
| Return Loss | ≥ 65 dB | |
| Operating Wavelength | 1310 nm / 1550 nm | |
| Operating Temperature | ‑40 °C to +75 °C | |
| Storage Temperature | ‑45 °C to +85 °C | |
| Applications | FTTx, telecom networks, data‑centre backbone links | |
| Compliance / Standards | IEC 61754‑20 (LC connector family); fiber meets ITU‑T G.657 | |
| Features | Bend‑insensitive G.657A2 fiber, precision LC/APC connector, LSZH jacket, factory‑tested performance | |
| Packaging | Individually packed with factory test report | |
