| Model |
LNM620X512G-RNNNG |
| Series |
NM620 |
| Capacity |
512GB |
| Interface |
PCIe Gen3x4 |
| Form Factor |
M.2 2280 |
| Sequential Read Speed |
Up to 3500 MB/s |
| Sequential Write Speed |
Up to 2400 MB/s |
| Random Read IOPS |
Up to 300,000 |
| Random Write IOPS |
Up to 256,000 |
| NAND Type |
3D TLC NAND |
| Controller |
DRAM-less (Silicon Motion SM2263XT or equivalent) |
| DRAM Cache |
No (uses Host Memory Buffer) |
| SLC Caching |
Yes (Dynamic SLC Cache) |
| Endurance (TBW) |
~250 TBW |
| MTBF |
1.5 million hours |
| Operating Temperature |
0°C to 70°C |
| Power Consumption |
Low power design |
| Heatsink |
Not included |
| Compatibility |
Laptops, Desktops with M.2 NVMe slot |
| Warranty |
5-Year Limited Warranty |
