| Product Name |
APC BACK‑UPS CS 650VA 230V ASEAN |
| Manufacturer |
APC by Schneider Electric |
| Model Number |
BK650‑AS |
| UPS Type |
Standby UPS |
| Rated Power Capacity |
650 VA / 400 W |
| Nominal Output Voltage |
230 V AC |
| Topology |
Standby with stepped approximation to a sinewave |
| Input Voltage Range |
160–282 V (adjustable) |
| Input Frequency |
50/60 Hz ±3 Hz auto‑sensing |
| Output Connections |
4 × IEC 60320 C13 (3 battery‑backup & surge, 1 surge only) |
| Batteries |
Maintenance‑free sealed lead‑acid battery (1 × RBC17) |
| Typical Recharge Time |
~8 hours |
| Expected Battery Life |
~4–6 years |
| Surge Protection |
Surge energy rating ~320 J |
| Control & Indicators |
LED indicators + audible alarms (on battery, low battery, overload) |
| Communication Ports |
USB interface for management (software) |
| Form Factor |
Tower, not rack‑mountable |
| Dimensions (H×W×D) |
165 × 91 × 284 mm |
| Net Weight |
~6.04 kg |
| Operating Temperature |
0 °C – 40 °C |
| Operating Humidity |
5 % – 95 % non‑condensing |
| Color |
Beige |
| Application |
Battery backup for PCs, network devices, and electronics in ASEAN 230 V environments |
